BOFA L1974 laser fume extraction system

Laser cutting, engraving, welding, coding, and marking
Industrial fume and particulate extraction
Electronics, automotive, medical, and packaging sectors

You can become a member here to see prices and take advantage of other privileges.

Adet

Request an offer

Ask a question

The BOFA L1974, known as the AD Oracle iQ, is a high-performance laser fume extraction system. It features a compact design and the advanced iQ Operating System, offering real-time performance monitoring, filter status tracking, and maintenance scheduling. Equipped with HEPA and activated carbon filters, it captures 99.995% of harmful particles. Additional features include automatic airflow control, low noise operation, and an integrated compressor

Airflow: 223 CFM / 96 mbar
Noise Level: <60 dBA (typical speed)
Electrical: 90–257V, 1 phase, 50/60Hz
Power: 1.1 kW / 12.5 A
Dimensions: 975 x 455 x 505 mm (H x W x D)
Weight: 65 kg
Filters:
- Pre-filter: DeepPleat DUO
- Main filter: HEPA (99.995% @ 0.3 microns)
- Gas filter: Activated carbon
Approvals: CE, UKCA, UL, cUL
Extras: VOC sensor, USB data export, system fault signal
