END ARMATUREN KA26-ED43 double-acting pneumatic actuated motorized ball valve
- Industrial automation systems
- Shut-off of neutral gases and liquids
- HVAC systems
- Chemical and process industries
- Food and beverage production lines
The END Armaturen KA26-ED43 is a motorized ball valve with a double-acting pneumatic actuator. It features a brass body and PTFE/FKM seals, suitable for neutral gases and liquids. The valve includes a mounting pad according to ISO 5211 and has a 2-part screwed body design that is maintenance-free and full-bore
- Model: KA26-ED43
- Type: 2-way ball valve
- Body Material: Brass
- Seal Material: PTFE / FKM
- Connection Type: Female thread (ISO 228)
- Nominal Pressure: PN16
- Size: 1 1/4"
- Actuator: ED43, double-acting pneumatic
- Body Design: 2-piece, screwed
- Mounting: ISO 5211 mounting pad
- Application: Shut-off of neutral gases and liquids
- Approval: AD-Approval A4
