The ERHARDT+LEIMER 00457277 is a flange-type load cell from the PD 21/22 series, designed for web tension measurement applications. It offers a nominal measuring force of 0.15 kN and ensures high reliability and precision.

Nominal force: 0.15 kN
Protection class: IP50
Accuracy class: 0.5
Measuring principle: Full bridge strain gauge
Bridge resistance: 700 Ohm
Supply voltage: 10 V (max. 14 V)
Temperature range: -10 °C to +90 °C
Nominal deflection: 0.1–0.2 mm
Overload protection: Up to 20x nominal force
Mounting options: Flange, pedestal, or body-mounted
