GEFRAN GRS-H-120-48-D-0-FAN60-0-0 GRS-H Series Solid State Relay
GEFRAN GRS-H-120-48-D-0-FAN60-0-0 GRS-H Series Solid State Relay
GEFRAN GRS-H-120-48-D-0-FAN60-0-0 GRS-H Series Solid State Relay
GEFRAN GRS-H-120-48-D-0-FAN60-0-0 GRS-H Series Solid State Relay

GEFRAN GRS-H-120-48-D-0-FAN60-0-0 GRS-H Series Solid State Relay

  • Industrial furnaces (heating control)
  • Plastic processing machinery (heater control)
  • Textile machinery (heating control)
  • Food processing equipment (heating control)
  • Packaging machinery (heating and sealing control)
  • Drying systems
  • Paint drying ovens
  • Ceramic and glass production equipment
  • Semiconductor manufacturing equipment
  • General industrial heating applications
    • You can become a member here to see prices and take advantage of other privileges.
    Ask a question
    GEFRAN GRS-H-120-48-D-0-FAN60-0-0 is a single-phase solid state relay (SSR) from the GRS-H series, featuring an integrated heatsink and fan, designed for switching AC loads up to 120A nominal current and 480Vac nominal voltage. The "D" coding typically indicates a DC control input (e.g., 6-32VDC). The "FAN60" designation signifies an integrated fan cooler to ensure full performance up to an ambient temperature of 60°C. This relay utilizes zero crossing switching (ZC) to reduce inrush currents and electromagnetic interference (EMI). Its compact design and push-in control terminals allow for easy installation and connection. It may also feature optional thermal alarm and load break alarm functionalities.
  • Product Code: F068786
  • Series: GRS-H
  • Type: Single-Phase Solid State Relay
  • Nominal Current (I_n): 120 A
  • Nominal Voltage (U_n): 480 Vac
  • Control Input Voltage: 6 - 32 VDC
  • Switching Type: Zero Crossing (ZC)
  • Cooling: Integrated Fan (FAN60 - performance up to 60°C)
  • Mounting: DIN Rail
  • Terminal Type (Control): Push-in terminals
  • Terminal Type (Power): Cage clamps
  • Alarm Options: Thermal alarm (optional), Load break alarm (optional)
  • LED Indicators: Input control status, alarm status (optional)
  • Protection: Overvoltage protection (MOV)
  • Certifications: CE, UL, CSA, EAC (to be verified)
  • Application Areas: Industrial heating, plastic machinery, furnaces, packaging machinery, etc. single-phase AC load control
  • Features: Compact size, integrated heatsink and fan, easy mounting, reliable switching, low EMI
