GEFRAN M21-6-M-B01M-1-4-D 2130X000X00 melt pressure transmitter

Plastic extrusion machinery (production of film, pipes, profiles, etc.)

Plastic injection molding machinery

Rubber extrusion and injection molding machinery

Laboratory and testing equipment (polymer melt pressure measurement)

You can become a member here to see prices and take advantage of other privileges.

Adet

Request an offer

Ask a question

GEFRAN M21-6-M-B01M-1-4-D is a melt pressure transducer from the M21 series with a measurement range of 0-6 bar, an M-type connection, a B01M electrical connection configuration, a 1/4" process connection, and a D output signal (typically 4-20mA). The additional coding "2130X000X00" specifies Gefran's specific product configuration. The M21 series utilizes the hydraulic pressure transmission principle for accurate and reliable pressure measurement of molten material at high temperatures. A special filling fluid (mercury) is used to ensure temperature stability. This model features a rigid stem.

Product Code: F008374 (possible code)

Series: M21 (Mercury Filled, Rigid Stem Melt Pressure Transducer)

Measurement Range: 0 - 6 bar

Accuracy: < ±0.5% FSO (M) (specified accuracy class)

Connection Type: Type M

Electrical Connection: B01M (6-pin connector)

Process Connection: 1/4" UNF

Output Signal: D (Typically 4-20 mA)

Filling Material: Mercury

Maximum Process Temperature: Up to 400°C

Stem Type: Rigid

Additional Coding: 2130X000X00 (Gefran specific configuration)

Application Areas: Plastic and rubber processing, high-temperature melt pressure measurement

Features: High-temperature resistance, reliable performance, rigid stem
