GEFRAN ME1-6-M-B35D-1-4-D melt pressure sensor

Plastic extrusion machinery (production of film, pipes, profiles, etc.)

Plastic injection molding machinery

Rubber extrusion and injection molding machinery

Laboratory and testing equipment (polymer melt pressure measurement)

You can become a member here to see prices and take advantage of other privileges.

Adet

Request an offer

Ask a question

GEFRAN ME1-6-M-B35D-1-4-D is a melt pressure sensor from the ME1 series with a measurement range of 0-350 bar, an M-type connection, a B35D electrical connection configuration, a 1/4" process connection, and a D output signal (typically 4-20mA). The additional coding "2130X000X00" specifies Gefran's specific product configuration. The ME1 series utilizes the hydraulic pressure transmission principle for accurate and reliable pressure measurement of molten material at high temperatures. A special filling fluid is used to ensure temperature stability. This model features both a rigid stem and a flexible tip.

Product Code: F007725 (possible code)

Series: ME1 (Rigid Stem + Flexible Tip Melt Pressure Sensor)

Measurement Range: 0 - 350 bar

Accuracy: < ±0.5% FSO (M) (specified accuracy class)

Connection Type: Type M

Electrical Connection: B35D (6-pin connector)

Process Connection: 1/4" UNF

Output Signal: D (Typically 4-20 mA)

Filling Material: Not specified (refer to datasheet)

Maximum Process Temperature: Up to 400°C

Stem Type: Rigid Stem + Flexible Tip

Additional Coding: 2130X000X00 (Gefran specific configuration)

Application Areas: Plastic and rubber processing, high-temperature melt pressure measurement

Features: High-temperature resistance, reliable performance, combination of rigid stem and flexible tip
