GEFRAN MN2-6-M-B07C-1-4-D 2130X000X00 Melt Pressure Sensor Turkey authorised distributor, sensor, encoder, controller

GEFRAN MN2-6-M-B07C-1-4-D 2130X000X00 Melt Pressure Sensor

Plastic Extrusion Machines: Melt pressure control in processes such as film, profile, and pipe extrusion.

Plastic Injection Molding Machines: Monitoring and control of melt pressure within the mold cavity.

Resin Transfer Molding (RTM): Measurement of resin pressure inside the mold.

Laboratory and Testing Applications: Investigation of the rheological properties of polymer melts.

You can become a member here to see prices and take advantage of other privileges.

Adet

Request an offer

Ask a question

GEFRAN MN2-6-M-B07C-1-4-D 2130X000X00 is a mercury-filled, high-temperature resistant melt pressure sensor. This series can measure the temperature of the molten material up to 400°C. The pressure is transmitted through a hydraulic system and converted into an electrical signal using strain-gauge technology. The "B07C" code indicates a pressure measurement range of 0 to 700 bar. The "1-4-D" configuration specifies a particular electrical output signal (typically voltage output) and the connection type. Its robust construction and high accuracy ensure reliable pressure measurement in demanding industrial conditions.

Model: MN2-6-M-B07C-1-4-D 2130X000X00

Sensor Type: Melt Pressure Sensor

Measuring Principle: Strain-Gauge

Filling Material: Mercury Filled

Pressure Range: 0 - 700 bar

Output Signal: Voltage Output (Refer to the product datasheet for details)

Accuracy: <±0.5% FS (Typical)

Operating Temperature (Media): Maximum 400°C (752°F)

Process Connection: G1/2" (Other connection types may be available)

Electrical Connection: Not specified (Usually connector-based)

Protection Class: IP65

Data Sheet
