GEFRAN PK-M-0300 LINEAR TRANSDUCER

Plastic Injection Molding Machines: Mold positioning, ejector position control.

Metalworking Machines: Bending presses, shears, various positioning applications.

Woodworking Machines: Position control of saws and other equipment.

Special Machines: Any application requiring precise measurement of linear movement.

You can become a member here to see prices and take advantage of other privileges.

Adet

Request an offer

Ask a question

GEFRAN PK-M-0300 is a rodless linear transducer operating on the potentiometric principle with a measuring range of 300 mm. It offers easy installation thanks to its self-aligning ball joint mechanical linkage and M5 threaded connection points. There is no variation of the electrical output signal outside the theoretical electrical stroke, which simplifies setup. The new fastening grooves provide an alternative mounting option to using brackets. It has an IP40 protection class and delivers reliable performance in harsh industrial environments.

Model: PK-M-0300

Sensor Type: Potentiometric Linear Transducer (Rodless)

Measuring Range (Electrical Stroke): 300 mm

Independent Linearity (Within C.E.U.): ± 0.05%

Resolution: Infinite

Repeatability: 0.01 mm

Mechanical Linkage: Self-aligning ball joint, M5 thread

Electrical Connection: DIN 43650 - ISO 4400, 4-pin connector

Maximum Operating Speed: ≤ 10 m/s

Vibration: 5...2000 Hz,

A_{ma x} = 0.75

mm,

a_{ma x} = 20

Shock: 50 g, 11 ms

Maximum Applicable Voltage: 60 V

Operating Temperature: -30 °C to +100 °C

Protection Class: IP40
